GRILLO DUMPER 406 TRACKED CARRIER

Name: GRILLO DUMPER 406 TRACKED CARRIER
SKU: GRILLO-DUMPER406
Availability: InStock

The rubber track carrier with 400 kg load capacity!
The compact and rapid rubber track carrier Dumper 406 is ideal for the transport of any kind of material in different sectors such as agriculture, zootechny, industry and gardening. The completely mechanized traction allows the full exploitation of the engines power. The rubber tracks with chain links made of steel and the optional engine types are the basis for a useful carrying capacity of the body 400 kg

Enquire for price

Export as PDF Print

VIEW PARTS/ACCESSORIES

HIDE PARTS/ACCESSORIES

VIEW PARTS/ACCESSORIES

DISCLAIMER

The material and information contained on this website is for general information purposes only. You should not rely upon the material or information on the website as a basis for making business, legal, or any other decisions.

Whilst we endeavour to keep the information up to date and correct, Agpower makes no representations or warranties of any kind, express or implied about the completeness, accuracy, reliability, suitability, or availability with respect to the website or the information, products, services, or related graphics contained on the website for any purpose. Any reliance you place on such material is therefore strictly at your own risk.

PRICING & STOCK AVAILABILITY

Due to stock availability changing daily, you can submit an order enquiry for this product, combined with other products on our website, using our ADD TO WISHLIST feature. This is not a commitment to purchase, only an order enquiry. A member of our team will contact you regarding stock availability, pricing and pick up/delivery options. Alternatively, you can contact us via our Product Enquiry form below.

Engine: Kohler 3000 Series OHV, Start recoil starter, Supply fuel, Displacement 196 cc, 1 Cylinder, Power 5.5 HP (4.1 kW), Air cooled, Dry air filter with interchangeable filter cartridges
Engine: Honda GX200 OHV, Start recoil starter, Supply fuel, Displacement 196 cc, 1 Cylinder, Power 5.5 HP (4.1 kW), Air cooled, Oil bath air filter
Fuel tank capacity: 3.6L eng. Kohler 3000; 3.1L. Honda GX200
Transmission: with oil bath gears
Traction: with rubber tracks with inner steel links
Gearbox: 3 forward gears + 3 reverse gears
Clutch: clutch per belt tension
Supporting surface of the track: 70 cm
Load bed: Equipped with side dump boards through gas springs
Capacity: 400 kg
Speed: 1st gear 1,0 km/h, 2nd gear 2,0 km/h, 3rd gear 3,5 km/h, 1st reverse gear 1,0 km/h, 2nd reverse gear 2,0 km/h, 3rd reverse gear 3,5 km/h
Steering wheel: with clutches in oil bath combined with brakes
Safety devices: automatic handbrake
Length: 161 cm
Width: 78 cm
Height: 110 cm
External sizes of the track: 65 cm
Weight: with Kohler 3000 engine 267 kg – with Honda GX200 engine 268 kg
